Introduction

Flat Pack Container House

Flat pack container hosue is an integrated and modular temporary or movable building unit, usually composed of steel frame and sandwich panels, with the characteristics of fast assembly, easy transportation, and reusability. flat pack container house, with "prefabrication, modularization, and rapid assembly" as their core advantages, fill the gap between traditional buildings and simple temporary facilities in terms of efficiency, cost, and flexibility. They are particularly suitable for scenarios that are sensitive to construction cycles and relocation needs, and are one of the mainstream choices in the field of modern temporary construction.

Core advantages of flat pack container house

Efficient installation and transportation

Quick on-site installation: No complex construction is required, and a single person or team can complete the assembly of a single compartment in 2-4 hours (traditional brick and concrete buildings take several weeks), suitable for emergency needs scenarios.

Low transportation cost: A single box can be lifted and transported as a whole, or disassembled into frames and boards for transportation (some products can be folded). One truck can load multiple units, reducing logistics costs.

Flexible reuse and relocation

Removable and reusable, only requiring disassembly and transportation during relocation, with a low loss rate and an average service life of 10-15 years, suitable for projects that require frequent movement (such as site relocation and activity evacuation).

Cost effectiveness and practicality

The cost per square meter is about 75-150USD (depending on the material configuration), which is 30% -50% lower than traditional buildings, and the maintenance cost is low (surface anti-corrosion treatment, not easy to rust or leak).

Strong functional adaptability: can be customized according to needs for dormitories, offices, bathrooms, kitchens, equipment rooms, etc., with flexible internal space layout (such as removable and adjustable partition walls).

Comparison with other temporary buildings

Type	Flat pack container house	Traditional container house	Brick and concrete temporary building
Installation time	2-4 hours/Unit	4-8 hours/Unit	weeks - months
Transportation flexibility	can be disassembled/folded, transportation efficiency is high	overall transportation is fixed in volume and cannot be transported	It needs to be dismantled and rebuilt
Spatial scalability	Modular splicing, flexible combination	The difficulty of splicing is high, and the space is fixed	Need to rebuild, high expansion cost
Cost	Low cost (high cost-effectiveness)	medium high (high transportation and installation costs)	high (high material and labor costs)

product lightweight portable steel flat pack container house easy to load and fit for small scale work sites or dormitory for villas-2

Technical information of flat pack container house

Size	Length	6058mm / 5800mm
		Width	3000mm/ 2438mm
		Height	2891mm
Standard accessories	Roof System	Top structure (steel structure + 0.45mm steel sheet + 100mm glass wool insulation)
		Chassis System	steel struction chassis + 18mm thickness cement-fiber board + 2mm thickness PVC floor sheet (for cold climate, we can add bottom insulation)
		Chassis System		Permitted loading:2.5KN/m2
		Wall System	sandwich panel, could be EPS sandwich panel, rock wool sandwich panel, glass fiber sandwich panel, or PU sandwich panel according to different requests. The thickness could be 50mm, 75mm, 100mm
		Door System	Steel security door / Fire-proof door / Sandwich panel door
		Window System	Aluminum alloy shutter window and the plastic-steel window, single or double glazed
		Floor System	PVC, plywood or customized
Option	Drainage system	Provided plan, design and construction
Option		Electric system	Provided plan, design and construction
Technical parameter	Resistant temperature	-40℃ to 40℃
		Wind resistance	210km/h
		Earthquake resistance	Grade 8

product lightweight portable steel flat pack container house easy to load and fit for small scale work sites or dormitory for villas-3

product lightweight portable steel flat pack container house easy to load and fit for small scale work sites or dormitory for villas-4

product lightweight portable steel flat pack container house easy to load and fit for small scale work sites or dormitory for villas-5

product lightweight portable steel flat pack container house easy to load and fit for small scale work sites or dormitory for villas-6

product lightweight portable steel flat pack container house easy to load and fit for small scale work sites or dormitory for villas-7

product lightweight portable steel flat pack container house easy to load and fit for small scale work sites or dormitory for villas-8

product lightweight portable steel flat pack container house easy to load and fit for small scale work sites or dormitory for villas-9

product lightweight portable steel flat pack container house easy to load and fit for small scale work sites or dormitory for villas-10

FAQ

1.Where is your factory?Our factory was located in Foshan City, Sanshui District, it’s about 40 minutes away from Guangzhou airport. 2.What are your main products?Our main products including steel structure warehouse/workshop, container house, prefab house, and color steel sandwich panels.3.What can you buy from us?We have several products series, such as: container house, steel structure warehouse/workshop, prefabricated house and insulation panels. We also welcome flexible orders based on customers’ requirements.4.What’s the different between you foldable container house and other suppliers?Our foldable container houses are waterproofed structurally, rather than using sealant like other factories do. This ensures that they will never leak throughout their lifetime.5.How long is your delivery time?Generally delivery time it is within 10 days, definitely according to order quantity.6.What’s your payment terms?Generally practise is 30% T/T deposit and balance amount should be paid before delivery. For bulk order, 30% T/T deposit and balance amount paid by LC is acceptable.
