Introduction

Detachable Container House

Detachable Container House refers to a container house assembled by non - welding methods such as bolts and connectors. All structural components (frames, walls, roofs, floors, etc.) can be disassembled into independent units. During transportation, the space can be greatly compressed, and on - site rapid reassembly can be carried out through a standardized process. This not only retains the structural strength of traditional containers but also solves the problems of high overall transportation costs and difficult disassembly and assembly.

Core advantages of Detachable Container House

Ultimate Transportation Economy

Traditional container house needs to be transported as a whole, and the single box occupies a large space (such as 20-foot box can only be loaded with 1 when transporting); whereas, the components of the disassembled container house can be folded or stacked, and can be loaded with 3-5 sets of components in the same transport space, which reduces the cost of transportation by 60%-70%, and is especially suitable for long-distance cross-border transportation or large-scale projects.

Quick disassembly, assembly and reuse

No professional welders are required. It is assembled through standardized connectors (such as high-strength bolts and buckles). A 2 - 3 - person team can complete the construction of a standard container within 8 - 12 hours. After disassembly, the component loss rate is less than 5%, and it can be repeatedly disassembled and assembled more than 50 times. It is suitable for short - term projects (such as exhibitions, emergency disaster relief) or scenarios that require frequent relocation (such as mobile camps, temporary workstations).

Structural Strength and Environmental Adaptability

The frame is made of Q355 high-strength steel, with a wind-resistance grade of 12 and a seismic grade of 7, which can withstand severe weather such as torrential rain and strong winds; the wall can be made of optional rock wool, polyurethane and other thermal insulation materials, and with the sealing design, it can still maintain a comfortable indoor temperature under the environment of - 30℃ to 40℃, and can adapt to a wide range of geographic regions such as high altitude, severe cold and high temperature.

Highly customizable potential

Internally, it can be customized according to requirements: the wall can be installed with wooden boards, gypsum boards or fireproof boards, and the floor can be selected from PVC, solid wood or anti - slip steel plates. At the same time, it supports the pre - installation of water and electricity systems, air conditioners, bathroom facilities, etc. Externally, any color or pattern can be sprayed, and even balconies and sunshades can be added, taking into account both functionality and aesthetics. It is suitable for scenarios such as cultural and tourism homestays and characteristic shops.

product compact detachable container house for small scale construction camps space saving stackable steel sandwich panel outdoor villas-2

product compact detachable container house for small scale construction camps space saving stackable steel sandwich panel outdoor villas-3

Technical information of Detachable Container House

Frame	Q235
Steel Material	All Steel Galvanized+baking Powder Paint
Roof board	Insulation Board with Corrugated Steel Plate walPanell
Wall Panel	50 mm/75 mm thickness EPS/Rock wool/PU Sandwich Panels
Floor	Galvanized Square tube Waterproof Plywood/Fiber Cement Board/18 mm Bolivian Magnesium Board+PVC Viny1 Floor Finishing
Door	930 mm(W)*1980 mm(H)Steel security door / Fire-proof door /Sandwich Panel Door with Handle & Lock
Window	930 mm(W)*1200 mm(H) PVC/Aluminum alloy Sliding/Tilt Window
Bolts	Galvanized M12 High-Strength Bolts
Light	LED Ceiling Lights Optional
Switch	1-Way-Switch Optional
Distribution Box	On ceiling,for Lights Optional
Stairs	Steel Stairs with high class Handrail Optional
Walkway+Balustrade+Awning	Galvanized Steel Optional
Roof Load	≥50Kilograms/m2
Flooring Load	≥150Kilograms/m2
Aisle Load	≥200Kilograms/m2
Wall Side Stress	≥80Kilograms/m2
Wall Deformation	≤300Kilograms/m2
Electrical System	Circuits Concealed,Match 3C/CE/AS
Drainage/Electric System	Provided Plan,Design and Construction
Resistant Temperature	-40℃ to -40℃
Wind Resistance	120 km/h or 11 level of wind Loading
Earthquake Resistance	Grade 8

product compact detachable container house for small scale construction camps space saving stackable steel sandwich panel outdoor villas-4

product compact detachable container house for small scale construction camps space saving stackable steel sandwich panel outdoor villas-5

product compact detachable container house for small scale construction camps space saving stackable steel sandwich panel outdoor villas-6

product compact detachable container house for small scale construction camps space saving stackable steel sandwich panel outdoor villas-7

product compact detachable container house for small scale construction camps space saving stackable steel sandwich panel outdoor villas-8

product compact detachable container house for small scale construction camps space saving stackable steel sandwich panel outdoor villas-9

FAQ

1.Where is your factory?Our factory was located in Foshan City, Sanshui District, it’s about 40 minutes away from Guangzhou airport. 2.What are your main products?Our main products including steel structure warehouse/workshop, container house, prefab house, and color steel sandwich panels.3.What can you buy from us?We have several products series, such as: container house, steel structure warehouse/workshop, prefabricated house and insulation panels. We also welcome flexible orders based on customers’ requirements.4.What’s the different between you foldable container house and other suppliers?Our foldable container houses are waterproofed structurally, rather than using sealant like other factories do. This ensures that they will never leak throughout their lifetime.5.How long is your delivery time?Generally delivery time it is within 10 days, definitely according to order quantity.6.What’s your payment terms?Generally practise is 30% T/T deposit and balance amount should be paid before delivery. For bulk order, 30% T/T deposit and balance amount paid by LC is acceptable.
